Overview
The 707 was not the first jet airliner, but it was the one that made jet travel common, halving journey times compared with propeller airliners. Specifications shown are for the long-range 707-320B.
Military derivatives such as the KC-135 tanker and the E-3 Sentry AWACS kept the design flying for decades.
Specifications
Dimensions
| Length | 46.60 m |
|---|---|
| Wingspan | 44.42 m |
| Height | 12.93 m |
| Wing area | 283.4 m² |
Weights & fuel
| Empty weight | 66,406 kg |
|---|---|
| Max. take-off weight | 151,320 kg |
| Fuel capacity | 90,300 L |
Performance
| Max. speed | 1,010 km/h |
|---|---|
| Cruise speed | 897 km/h |
| Range | 9,265 km |
| Service ceiling | 12,800 m |
Crew & capacity
| Crew | 3–4 |
|---|---|
| Seats (typical) | 141 |
| Seats (max.) | 189 |
Powerplant
| Engines | 4 |
|---|---|
| Engine model | Pratt & Whitney JT3D (707-320B) |
| Thrust (each) | 80.0 kN |
Figures are compiled from public sources and may be approximate; they can vary by variant and configuration.
